Figure 7-12 Installing battery module power cables (capacity expansion scenario)
● In capacity expansion scenarios, you need to purchase bottom cascading cables
from Huawei Digital Power.
● Bottom cascading cables must be routed from the rear of the product.
● Cables outside the device must be routed through cable pipes.
----End
7.6 Installing Cascading Signal Cables Between Battery
Modules
When a communications terminal is connected to a single network cable, a
waterproof rubber plug must be installed.
