Huawei iSitePower-M User Manual

Pin Signal Description
7 GND2 NC
8 STDA_TX- Signal
9 STDA_TX+ Signal
Table 4-15 Frequency bands supported by the 4G wireless backhaul
Frequency Band Transmit (Tx) Receive (Rx)
GSM 850 824 MHz–849 MHz 869 MHz–894 MHz
GSM 900 880 MHz–915 MHz 925 MHz–960 MHz
GSM 1800 1710 MHz–1785 MHz 1805 MHz–1880 MHz
GSM 1900 1850 MHz–1910 MHz 1930 MHz–1990 MHz
iSitePower-M (MAP05A1, MAB05B1)
User Manual 4 Components
Issue 02 (2021-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 33

Huawei iSitePower-M Specifications

General

Storage Temperature	-40°C to +70°C
Product Name	Huawei iSitePower-M
Type	Power System
Efficiency	≥96%
Output Voltage	-48 V DC
Operating Temperature	-40°C to +55°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 4000 m
Cooling Method	Forced Air Cooling
Protection Features	Overvoltage, undervoltage, overcurrent, short circuit, overtemperature
Certifications	CE, UL, TUV
Input Voltage Range	85 V - 300 V AC
