Step 3 Route the cables out of the cable holes.
The outlet positions shown in the gure are for reference only. Select an
appropriate cable outlet based on the actual cable thickness.
Figure 7-25 Cable routes
Step 4 Tighten the screws.
Figure 7-26 Installing the decorative covers
----End
iSitePower-M (MAP05A1, MAB05B1)
User Manual 7 Electrical Connection
Issue 02 (2021-12-30) Copyright © Huawei Digital Power Technologies Co., Ltd. 80
