NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm)
2 Product Description
Issue 13 (2019-01-15)
Copyright © Huawei Technologies Co., Ltd.
19
Name
Specifications
Unit
Hydrogenion
7–8.5
pH
Conductivity rate at 20°C (σ
20
)
a
300–1250
μS/cm
a: When σ
20
is less than 300 μS/cm, the first vapor exhausting duration of the humidifier is
long; when σ
20
greater than 1250 μS/cm, the humidifier service life is affected.
2.4 Technical Specifications
Table 2-10 General Parameters
Item
NetCol5000-A035
NetCol5000-A025
Cooling Mode
Air cooled
Air cooled
Refrigerant
R410A
R410A
Cooling capacity
a
35 kW
25 kW
Air supply mode
Horizontal air supply
Horizontal air supply
Airflow
6800 m
3
/h
4600 m
3
/h
Air filter
G4 filter
G4 filter
Dimensions (H x D x
W)
b
2000 mm x 600 mm x 1100
mm
2000 mm x 600 mm x 1100
mm
a: Indoor dry-bulb temperature: 37.8°C. Wet-bulb temperature: 20.8°C. Condensing
temperature: 45°C.
b: Frames can be used to expand the depth to 1200 mm, while top supports can be used to
top frame to 2200 mm.

When the total load of servers, relative to a single smart cooling product, is less than 10
kW, smart cooling products that have heating and humidification functions or partial
heating and humidification functions are recommended.

The condensate pump is mandatory for scenarios where pipes are routed from the top or if
it is required by the customer.
Table 2-11 Optional Parameters of NetCol5000-A035
Item
NetCol5000-A
035H512D2E1
20E1
NetCol5000-A
035H512D2E1
20E0
NetCol5000-A
035H512D200
20E1
NetCol5000-A
035H512D200
20E0
Max Current
32 A
32 A
26 A
26 A
