Huawei NetCol5000-A-035 - Deployment Principles

NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm)
3 Installation Guide
Issue 13 (2019-01-15)
Copyright © Huawei Technologies Co., Ltd.
31
Table 3-10 Cable specifications
Name
Specifications
Quantity
Remarks
Indoor unit
power cable
Four-core cable
a
: electrical power cable-600
V/1000 V-ZA-RVV-6 mm
2
-46 A
1 PCS (The
length is
determined
in presale
survey.)
Optional
L1, L2, and L3 terminals: common
terminal-single cord end terminal-6
mm
2
-0.02 m-30 A-inserted depth 12 mm
6 PCS
Mandatory
PE terminals: naked crimping terminal-OT-6
mm
2
-M6-50 A-tin plated-12 AWG to 10
AWG
2 PCS
Mandatory
Outdoor
unit power
cable
For detail cable specifications, see the
outdoor unit user manual.
1 PCS
Optional
Voltage
jumper
Six voltage jumpers are available in the
fitting bag. Select one for use.
1 PCS
Mandatory
Outdoor
unit on/off
signal cable
For details about the cable specifications, see
the outdoor unit user manual.
1 PCS
Optional
Water
sensor
signal cable
Power cable-5m-22AWG-(2 x T0.5
2
)-(2 x
22UL1007)-(2 x T0.5
2
)
1 PCS
Mandatory
Teamwork
networking
cable
It also can be used for host monitoring.
1 PCS
(10m)
Mandatory
Humidity
and
temperature
sensor and
its cable
N/A
Max 6 PCS
Optional
a: If you use a five-core cable, do not install the neutral wire (blue). Instead, cut off it and
properly wrap PVC insulation tape around the cutting place. Purchase indoor unit power
cables with qualified diameters (16.8–18 mm). Otherwise, the power cables will fail to be
routed through the clip.
3.1.3 Deployment Principles
Precautions

Check cabinets comprehensively and handle problems immediately.

Before installation, check that the environment meets requirements and check whether
reconstruction is needed for routing pipes and cables and constructing ventilation pipes.
