NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm)
Copyright © Huawei Technologies Co., Ltd.
Mandatory: mandatory configuration. This material is provided by Huawei and can be
found in delivered fittings.
Optional: This material can be purchased from Huawei or prepared by yourself.
Engineering purchasing: This material is not configured by Huawei and must be
prepared by yourself.
Table 3-6 Material configuration
Pipe components
and supports
Humidifier water
supply/drainage
components
Cables and electric
device
L1, L2, L3 and PE
terminals (18 PCS),
voltage jumper (6 PCS),
water sensor (1 PCS),
teamwork networking
cable (1 PCS), humidity
and temperature sensor
(1 PCS)
Pipe components
(including R410A
copper pipes, thermal
insulation foam, oil
traps and inverted
traps)
Indoor unit power cable,
outdoor unit power
cable, outdoor unit on/off
signal cable, humidity
and temperature sensor
Conversion adapter,
rigid pipe or hose
3.1.2.1 (Optional) Refrigerant R410A
Do not use low-quality refrigerant. Huawei is not responsible for any damage caused by
low-quality refrigerant.
Follow these suggestions to choose high-quality refrigerant:
1. Use high-quality brands such as DuPont, Daikin, or Honeywell.
2. Contact the refrigerant producer to confirm the refrigerant authenticity.
3. Check the refrigerant by following the steps shown in Figure 3-1: Keep the refrigerant
indoors at a constant temperature and humidity for 24 hours. Use a thermometer to
measure the external surface temperature of the refrigerant container, and connect a
pressure gauge to the container to measure its internal pressure. Determine the saturation
pressure that corresponds to the measured external surface temperature according to
Table 3-7 and calculate the deviation from the measured internal pressure. If the
deviation is more than 0.2 MPa, the refrigerant is not qualified and should be replaced.
