NetCol5000-A(025, 035) In-row Air Cooled Smart
Cooling Product
User Manual (600 mm)
Copyright © Huawei Technologies Co., Ltd.
Controls the
temperature inside the
room or aisles based
on the Average,
Maximum, or
Minimum of the
temperatures collected
by each sensor.
Average: Select Average if the
temperature is to be controlled based on
the averaged data value collected by the
collector.
Maximum: Select Maximum if the
temperature is to be controlled based on
the maximum data value collected by the
collector.
Minimum: Select Minimum if the
temperature is to be controlled based on
the minimum data value collected by the
collector.
Supply-air temp
set point,
Supply-air humid
set point
Sets the required
humidity and
temperature in a room
or aisle.
The ACC controls the temperature and
humidity based on the set value. For example,
if Temp control type is set to Return-air,
Return-air temp set point is set to 30.0, and
Return-air humid set point is set to 25.0, the
ACC will control the temperature and
humidity around the return-air vent of the
smart cooling product to a temperature of
30°C and humidity of 25% RH.
Return-air temp
set point,
Return-air humid
set point
Cold-aisle temp
set point,
Cold-aisle humid
set point
Hot-aisle temp
set point,
Hot-aisle humid
set point
Cold aisle sensor
1, 2, 3
Sets the sensors in
cold aisles to Enable.
Enable the corresponding humidity and
temperature sensor installed in the cold aisle.
Sets the sensors in hot
aisles to Enable.
Enable the corresponding humidity and
temperature sensor installed in the hot aisle.
----End
4.3.2.4 Setting Communications Parameters (IP Address Settings)
Context
When the smart cooling product monitoring system connects to the ECC800, you do not
manually set the IP address and skip the operations in this section.
To set communications parameters, log in as the Admin, or Engineer user.
