Function description
Chapter 3 OPERATION MANUAL
V1.3.0en/06.07.15//14.06 Liability for errors and misprints excluded. CC®
Function E-grade Basic
E-grade
Exclusive
E-grade
Professional
Connections
Digital interface RS232
USB interfaces (Host and Device)
Ethernet RJ45 interface
Pt100 external sensor connection
External control signal / ECS STANDBY
1
Programmable floating contact / ALARM
2
AIF (Analog Interface) 0/4-20 mA or 0-10 V
3
Digital interface RS485
4
Comfort & other
Visual / audible alarm signal
Autostart (Power Failure Auto)
Plug & Play technology
Technology glossary
Remote control / data visualization via Spy software
E-grade evaluation versions available
(valid for 30 days)
Storage/loading temperature control programs onto
USB stick
Service data recorders (flight recorder)
Process data recording directly to a USB stick:
- Setpoint, actual value internally, actual value
process
- heating capacity %, cooling capacity %, pump
pressure, pump speed, VPC pressure
Calendar start
3.5 Clock/event function
3.5.1 Rechargeable accumulator
“Pilot ONE” is fitted with a clock that continues to run even when the temperature control unit is
switched off. The energy required for this purpose is provided by a rechargeable accumulator, which
is automatically charged when the temperature control unit is switched on. The accumulator is
dimensioned so that the clock can also continue to run for prolonged switch-off intervals (up to
several months). If, after extremely prolonged switch-off time, time and date have been deleted,
leaving the temperature control unit switched on for a few hours will usually suffice (no tempera-
ture control required). During this time, you can reset the time and date.
If after switching the unit off and back on again, the previously set time and date re-appear, it can be
safely assumed that the rechargeable accumulator is defective. In this case, contact Customer Sup-
port. The telephone number can be found on page 82 in section »Phone number and company
address«.
1
Standard on Unistats, otherwise via optional Com.G@te or POKO/ECS interface.
2
Standard on Unistats, otherwise via optional Com.G@te or POKO/ECS interface.
3
Via optional Com.G@te.
4
Via optional Com.G@te.
