2.4 Installation conditions
Temperature control unit is connected to the power supply line
DEATH FROM ELECTRICAL SHOCK BY DAMAGE TO THE POWER CABLE.
 Do not put temperature control unit on power cable.
Operating the temperature control unit fitted with castors without brakes activated
CRUSHING OF LIMBS
 Activate brakes on the wheels.
▪ Allow the temperature control unit to acclimate for about 2 hours when changing from a cold to a
warm environment (or vice versa). Do not turn on the temperature control unit before!
▪ Transport upright.
▪ Install upright, stable and without tilt.
▪ Use a non-combustible, sealed subsurface.
▪ Keep environment clean: Prevent slip and trip hazards.
▪ If wheels are present, they must be locked after the installation!
▪ Drip catcher below the temperature control unit for condensation/thermal fluid.
▪ Spilled/leaked thermal fluid must be discarded immediately and correctly.
▪ The responsible body must check whether national regulations require the mandatory installation
of a drain tray for the installation area of the temperature control unit/the entire system.
▪ Observe the floor load bearing capacity for large units.
▪ Observe the ambient conditions.
2.5 Recommended temperature control and cooling water hoses
Use of unsuitable/defective hoses and/or hose connections
INJURIES
 Thermal fluid
 Use appropriate hoses and/or hose connections.
 Check periodically for leaks and the quality of the hose and hose connections and take suitable
measures (replace) as required.
 Isolate and protect temperature control hoses against contact/mechanical load.
 Cooling water
 Reinforced hoses must be used to satisfy tougher safety requirements.
 Shut off the cooling water supply to the temperature control unit even for shorter downtimes
(e.g. overnight).
Hot or cold thermal fluid and surfaces
BURNS TO LIMBS
 Avoid direct contact with the thermal fluids or the surfaces.
 Wear your personnel protective equipment (e.g. temperature-resistant safety gloves, safety
goggles, safety footwear).
To connect applications, use only temperature control hoses that are compatible with the thermal
fluid used. When selecting temperature control hoses, also pay attention to the temperature range
in which the hoses are to be used.
▪ We recommend you use only temperature-insulated temperature control hoses with your tem-
perature control unit. The responsible body is responsible for the insulation of connection valves.
▪ We exclusively recommend reinforced hoses for connecting to the cooling water supply. Cooling
water and insulated temperature control hoses can be found in the Huber catalogue under Acces-
sories.
