Interfaces and software update
Chapter 6 OPERATION MANUAL
V1.3.0en/06.07.15//14.06 Liability for errors and misprints excluded. CC®
6.1.2 USB-2.0 interface
The interfaces used must meet the specifications of the generally accepted standards.
6.1.2.1 USB-2.0 interface, host
USB-2.0 connection (for connector A), e.g. for data memories.
6.1.2.2 USB-2.0 interface, device
USB-2.0 connection (for Mini-B connector) for communicating with a computer.
6.2 Cooling/heating baths: Interfaces at the back
6.2.1 Activation connector
This connector is used to connect the cooling bath with the hanger thermostat. This enables control
of the cooling bath via the hanger thermostat.
6.3 Cooling/heating baths: Interfaces on the hanger thermostat
Interfaces at the
back of the
cooling bath
Interfaces at the back
of the hanger thermo-
stat
