Humminbird HELIX 7 G2 SERIES User Manual

107
Screen Snapshots and Recordings
Take Screen Snapshots
S
creen Snapshots are saved pictures of the view on the screen. The screen snapshot will include the menus, dialog boxes, warnings,
and messages that were active when the screen snapshot was taken. If Screen Snapshot Waypoint is turned on, a waypoint will also
be saved at the boat or cursor location when you take a screen snapshot.
NOTE: A microSD card must be installed in the control head to use the Snapshot and Recording features.
1. From any view or cursor location you want to capture, press and hold the MARK key.
Taking a Screen Snapshot
Press and Hold to
Take a Screen Snapshot

Humminbird HELIX 7 G2 SERIES Specifications

General

Power Input	10-20 VDC
Operating Temperature	-15°C to 55°C
Water Rating	IPX7
GPS Chartplotting	Yes
Display Size	7 inches
Resolution	800 x 480 pixels
Sonar	Yes
Sonar Frequencies Supported	83 kHz, 200 kHz
Max Depth	1500 ft
Power Output	500 W RMS
GPS	Internal GPS
Memory Card Slot	microSD
Connectivity	Ethernet
