NOTES:
REFERENCE BOM P/N 610-003-015.
1.
PART OF LABEL SET P/N 000-081-039
ITEM'S 38 & 39 ONLY USED WITHOUT APO.
APO OPTIONAL
FLOAT SWITCH PART OF APO P/N 000-079-091
PART OF MACHINE PARTS KIT P/N 000-078-052
3
2
2
3
3
4
6
6
6
REVISIONS
LTR
REVISION
CODE
DATE
BY
CHKD
APPVD
A
ITEM 32 WAS 143-539; RELOCATED ITEMS
10,16,18 & 40; ADDED NOTE 5;
LRIP
01/16/2008
L.O.L.
B.R.T. B.R.T.
B
ITEM 48 WAS MISSING INFO. IN BOM;
ADDED ITEMS 31, 35 & NOTE 6;
RENUMBERD BOM & UPDATED NUMBERS
IN NOTES;
LRIP
2/26/2008
L.O.L.
B.R.T. B.R.T.
C
RENUMBERED BOM; DELETED P/N's 000-
143-001, 000-013-070 & 000-001-131; ADDED
ITEMS 46 & 47; CHANGED QTY OF ITEM 17
WAS 3 NOW IS 2, ITEM 25 WAS 14 NOW IS
18, ITEM 26 WAS 14 NOW IS 2, ITEM 29 WAS
12 NOW IS 4, CHANGE P/N OF ITEM 20 WAS
143-165 NOW IS 143-539; UPDATED NOTES;
REDRAWN IN SOLIDWORKS
ECR1572
12/8/2009
AJP
E.J. E.J.
47 8
NUT, 1/4"-20UNC NYLOCK
S STEEL
000-094-009
- - -
46 1
ADAPTER, TANK TO Ø2.5" x 90° BLOWER HOSE
STEEL
000-001-134
6887
45 1
DEFLECTOR, AIR - UNIVERSAL RECOVERY TANK
ALUMINUM
000-049-154
6905
44 1
LABEL, MAINTENANCE & LUBE SCHEDULE
3M 200 MP
ADHESIVE
SEE NOTES
6561
43 1
BRACKET, FLAT FILTER SECURING
ALUMINUM
000-015-932
6877
42 1
ELBOW, 1/4" NPT STREET x 45°
BRASS
000-052-082
- - -
41 1
ASSEMBLY, DURA-FLOW APO - PRODUCTION
VARIOUS
000-079-091
5654
40 2
CLAMP, 3/4" NYLON HOSE
NYLON
000-033-023
- - -
39 1
PLUG,1" NPT BLACK NYLON
BLACK
NYLON
000-106-049
- - -
38 1
PLUG, 1-1/4" NPT
ABS
000-106-046
- - -
37 1
PLUG, 1-1/2" NPT
PLASTIC
000-106-019
- - -
36 1
FILTER, RECOVERY TANK BASKET
VARIOUS
000-049-152
6850
35 6
RIVET, AB8-6A ALUMINUM POP
ALUMINUM
000-140-023
- - -
34 2
NUT, #10-24UNC NYLOCK
S. STEEL
000-094-034
- - -
33 4
WASHER, #10 FLAT RUBBER BACKED
S. STEEL
000-174-036
- - -
32 2
WASHER, #10 S/S FLAT
S. STEEL
000-174-001
- - -
31 2
SCREW, #10-24UNC x 0.75" LG. HEX HEAD
S. STEEL
000-143-132
- - -
30 4
NUT, 1/4"-20UNC NEOPRENE WELLNUT
NEOPRENE
000-094-113
- - -
29 12
SCREW, 1/4"-20UNC x 1.00" LG. HEX HEAD
S. STEEL
000-143-002
- - -
28 4
WASHER, 1/4" RUBBER BACKED
S. STEEL
000-174-060
- - -
27 2
SCREW, 1/4"-20UNC x 0.50" LG. HEX HEAD
S. STEEL
000-143-333
- - -
26 2
WASHER, 1/4" LOCK
S. STEEL
000-174-019
- - -
25 18
WASHER, 1/4" FLAT
S. STEEL
000-174-003
- - -
24 2
WASHER, 3/8" RUBBER BACKED
S. STEEL
000-174-029
- - -
23 2
SCREW, #8-32UNC x 3/4" LG. BINDER HEAD
S. STEEL
000-143-051
- - -
22 2
NUT, #8-32UNC NYLOCK
S. STEEL
000-094-059
- - -
21 2
NUT, #6-32UNC NYLOCK
304
000-094-063
- - -
20 2
SCREW, #6-32UNC x 0.50" LG. BUTTON HEAD
S. STEEL
000-143-539
- - -
19 1
FILTER, FLAT - UNIVERSAL RECOVERY TANK VARIOUS
000-049-153
6851
18 1
ASSEMBLY, VACUUM RELIEF VALVE - URT
VARIOUS
601-050-001
6894
17 2
GASKET, ADAPTER - URT
RUBBER
000-057-206
6897
16 1
LATCH, BUNGEE - STRIKE
VARIOUS
000-086-008
- - -
15 1
NIPPLE, 1-1/2" IPS CLOSE s/s
S. STEEL
000-052-763
- - -
14 1
BLOCK, 6 POST TERMINAL
VARIOUS
000-012-002
- - -
13 1
INSERT, 1-1/2" NPT x 1-1/2" BARB (GREY)
PVC
000-052-226
- - -
12 1
VALVE, 1-1/2" FULL PORT BALL
BRASS
000-169-022
- - -
11 1
FLOAT, LEVER SWITCH
VARIOUS
000-157-091
- - -
10 1
NIPPLE, 3/8" NPT x 1/4" M SAE
BRASS
000-052-662
- - -
9 1
VALVE, 12 VOLT SOLENOID 1200 PSI
BRASS
000-169-082
- - -
8 1
ELBOW, 1/4" FPT x FPT
BRASS
000-052-088
- - -
7 2
INSERT, #46 (1/4" NPT x 3/8" BARB)
BRASS
000-052-102
- - -
6 1
ELBOW, 1/4" NPT STREET
BRASS
000-052-085
- - -
5 1
NIPPLE, 3/8" NPT x 1/4" NPT HEX
BRASS
000-052-073
- - -
4 1
TEE, 1/4" NPT BRANCH M-F-F
BRASS
000-052-090
- - -
3 1
NIPPLE, 1/4" NPT HEX BRASS
000-052-071
- - -
2 1
ASSEMBLY, COVER - SINGLE VACUUM
VARIOUS
SEE NOTES
6891
1 1
TANK, 70 GALLON URT - WELDMENT
ALUMINUM
000-159-128
6862
ITEM NO.
QTY.
DESCRIPTION
MATERIAL
PART NO. DWG. NO.
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
MACHINE
FINISH
125
DRAWN
CHECKED
APPVD
SCALE: 1:8
SHEET 1 OF 1
DRAWING NUMBER
PROPRIETARY INFORMATION
11015 47th Avenue West,
Mukilteo, Washington 98275
D
SIZE
TOLERANCES
.X= .1
.XX= .03
.XXX= .010
ANGULAR= 1°
BREAK ALL SHARP EDGES 0.005-.015
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
PART NUMBER
CODE:
APPLICATION
NEXT ASSY
USED ON
L.O.L.
B.R.T.
01/10/2008
01/10/2008
01/10/2008
SEE NOTES
REV
ASSEMBLY, 70 GALLON URT
7067
C
B.R.T.
- - -
BOXXER 318
- - -
- - - - - -
