HydraMaster Boxxer 318 - Page 94

Machine Assemblies and Parts Lists: 8-30
70 Gallon Universal Recovery Tank Assembly Parts List
Item Part Number Description Qty Item Part Number Description Qty
1 000-159-128 Tank, 70 Gallon URT - Weldment 1
2 - - - Assembly, Cover - Single Vacuum 1
3 000-052-071 Nipple, 1/4" NPT Hex 1
4 000-052-090 Tee, 1/4" NPT Branch M-F-F 1
5 000-052-073 Nipple, 3/8" NPT X 1/4" NPT Hex 1
6 000-052-085 Elbow, 1/4" NPT Street 1
7 000-052-102 Insert, #46 (1/4" NPT X 3/8" Barb) 2
8 000-052-088 Elbow, 1/4" FPT X FPT 1
9 000-169-082 Valve, 12 Volt Solenoid 1200 psi 1
10 000-052-662 Nipple, 3/8" NPT X 1/4" M SAE 1
11 000-157-091 Float, Lever Switch 1
12 000-169-022 Valve, 1-1/2" Full Port Ball 1
13 000-052-226 Insert, 1-1/2" NPT X 1-1/2" Barb (Grey) 1
14 000-012-002 Block, 6 Post Terminal 1
15 000-052-763 Nipple, 1-1/2" Ips Close S/S 1
16 000-086-008 Latch, Bungee - Strike 1
17 000-057-206 Gasket, Adapter - URT 2
18 601-050-001 Assembly, Vacuum Relief Valve - URT 1
19 000-049-153 Filter, Flat - Universal Recovery Tank 1
20 000-143-539 Screw, #6-32UNC X 0.50" Lg. Button Head 2
21 000-094-063 Nut, #6-32UNC Nylock 2
22 000-094-059 Nut, #8-32UNC Nylock 2
23 000-143-051 Screw, #8-32UNC X 3/4" Lg. Binder Head 2
24 000-174-029 Washer, 3/8" Rubber Backed 2
25 000-174-003 Washer, 1/4" Flat 18
26 000-174-019 Washer, 1/4" Lock 2
27 000-143-333 Screw, 1/4"-20UNC X 0.50" Lg. Hex Head 2
28 000-174-060 Washer, 1/4" Rubber Backed 4
29 000-143-002 Screw, 1/4"-20UNC X 1.00" Lg. Hex Head 12
30 000-094-113 Nut, 1/4"-20UNC Neoprene Wellnut 4
31 000-143-132 Screw, #10-24UNC X 0.75" Lg. Hex Head 2
32 000-174-001 Washer, #10 S/S Flat 2
33 000-174-036 Washer, #10 Flat Rubber Backed 4
34 000-094-034 Nut, #10-24UNC Nylock 2
35 000-140-023 Rivet, Ab8-6a Aluminum Pop 6
36 000-049-152 Filter, Recovery Tank Basket 1
37 000-106-019 Plug, 1-1/2" NPT 1
38 000-106-046 Plug, 1-1/4" NPT 1
39 000-106-049 Plug,1" NPT Black Nylon 1
40 000-033-023 Clamp, 3/4" Nylon Hose 2
41 000-079-091 Assembly, Dura-Flow APO - Production 1
42 000-052-082 Elbow, 1/4" NPT Street X 45° 1
43 000-015-932 Bracket, Flat Filter Securing 1
44 - - - Label, Maintenance & Lube Schedule 1
45 000-049-154 Deector, Air - Universal Recovery Tank 1
46 000-001-134 Adapter, Tank To Ø2.5" X 90° Blower Hose 1
47 000-094-009 Nut, 1/4"-20UNC Nylock 8
