2-1: Installation Information
Figure 2-1. Location of
Roof Vents in Vehicle
2 - Installation Information
Although there are many different heavy duty vehicles used for carpet cleaning equipment,
the preferable vehicle for a Boxxer 423s installation is a cargo van with a heavy-duty
suspension package and a 3/4 HD ton capacity. If a fresh water tank is added, a one ton
or larger capacity van is required.
Prior to installation of the Boxxer 423s, HydraMaster recommends installing a spray-
on bed liner in the vehicle. This provides ‘metal to cushion’
mounting rather than ‘metal to metal’ and makes for an
attractive van interior.
HydraMaster also recommends installing roof vents in
vehicles operated in hot weather locations. Roof vent
positions are shown in Figure 2-1. Consult your local RV
distributor about selection and/or installation of powered
roof vents.
For best results, the fan should draw air into the vehicle
which will supply cooler air to the air cleaner intake.
HydraMaster requires a powered roof vent above the air cleaner intake. Failure
to install a powered roof vent in such a manner may result in serious component
or engine damage.
