9-46: Assemblies and Parts Lists 9-47: Assemblies and Parts Lists
70 Gallon Universal Recovery Tank (URT) Cover Assembly Parts List
1 000-041-443 Cover 1
2 000-052-219 Adapter, 2” NPT X 2” F Slip 1
3 000-052-222 Elbow, 2” Barb X 2” FPT 1
4 000-057-015 Gasket, 1-1/2” Bulkhead Fitting 1
5 000-057-202 Gasket, End - Recovery Tank Cover 2
6 000-057-203 Gasket, Middle - Recovery Tank Cover 2
7 000-057-204 Gasket, Side - Recovery Tank 2
8 - - - Latch, Bungee - Strike (Part of 000-086-008) 1
9 000-094-063 Nut, #6-32UNC Nylock 2
10 000-143-539 Screw, #6-32UNC X 0.50” Lg. Button Head 2
Item Part Number Description Qty Item Part Number Description Qty
Figure 9-33. 100 Gallon Universal Recovery Tank (URT) Assembly
610-003-423 Rev. B
The APO is optional equipment.
The lower oat switch is only
used when the APO is installed.
To Next Page
