Parts lists

DynaMAX 550P/560P/575P Waterjet Pump Operator Manual 811390 143

Hydraulic system

Part number Description

1-11733 Shift valve and pilot assembly, 24 VDC

1-17348 Transducer, hydraulic

1-17347 Valve and coil, proportional cartridge

1-17349 Relief valve, hydraulic high-pressure, preset

1-12617 Switch, temperature and fluid level

1-11964 Return diffuser, 2 inch

1-16435 O-ring kit, shift valve

1-18054 Service kit, gear pump, DynaMAX 550P/560P/575P

1-18042 Service kit, hydraulic pump, DynaMAX 550P

1-18043 Service kit, hydraulic pump, DynaMAX 560P/575P

1-18046 Service kit, hydraulic shaft seal, DynaMAX 550P

1-18047 Service kit, hydraulic shaft seal, DynaMAX 560P/575P

1-18050 Service kit, hydraulic O-rings, DynaMAX 550P

1-18051 Service kit, hydraulic O-rings, DynaMAX 560P/575P

1-18052 Service kit, compensator
