Specifications
176 811390 Operator Manual DynaMAX 550P/560P/575P Waterjet Pump
DynaMAX 550P
Dimensions and weights
The shipping weight is for the pump, the pallet, and the packaging. Exact weights are measured at
shipment. Operating weight is for an unpackaged pump with hydraulic fluid.
Electrical
Water
Length 196 cm (77 in.) Shipping weight 1,350 kg (3,000 lb)
Width 97 cm (38 in.) Operating weight 1,300 kg (2,800 lb)
Height 155 cm (61 in.)
37 kW, 50 hp 50 Hz 60 Hz
Voltage 400 V 208 V to 230 V 460 V
Full-load current 73.8 A 138.2 A to 125.8 A 62.9 A
Primary circuit breaker rating 80.0 A 150.0 A 80.0 A
Minimum Maximum
CUTTING WATER IN
Flow 7.6 L/minute (2 gallons/minute) —
Pressure 2.8 bar (40 psi) 7.6 bar (110 psi)
CUTTING WATER OUT
Flow — 3.8 L/minute (1 gallon/minute)
Pressure 345 bar (5,000 psi) 4,140 bar (60,000 psi)
Cut-pressure factory
setpoint
— 4,140 bar (60,000 psi)
Pierce-pressure
factory setpoint
1,380 bar (20,000 psi) —
COOLING IN and COOLING OUT
Flow 11.4 L/minute (3.0 gallons/minute) —
Pressure 2.8 bar (40 psi) 7.6 bar (110 psi)
