Specifications
186 811390 Operator Manual DynaMAX 550P/560P/575P Waterjet Pump
Incorrectly installed collar: The collar interferes with the sealing surface.
Correctly installed collar: The sealing surface is showing.
4. Push the high-pressure tube fully into the fitting.
5. Tighten the gland nut by hand.
6. Use a torque wrench to tighten the gland nut to the specified value.
Low-pressure water fittings
All low-pressure water connections use push-to-connect fittings.
Do not use lubricants on low-pressure water fittings.
