IAI XSEL User Manual

521
Appendix
Appendix
INTELLIGENT ACTUATOR
(In the panel window, the three digits after “E” indicate an error number.)
Error No. Error name Description, action, etc.
D58 Fieldbus error (INIT timeout) An INIT timeout was detected.
Check the statuses of monitor LEDs on the front panel of the board by referring to the operation manual for the field network board.
D59 Fieldbus error (DPRAM write/read) A DPRAM write/read error was detected.
Check the statuses of monitor LEDs on the front panel of the board by referring to the operation manual for the field network board.
D5A Fieldbus error (TOGGLE timeout) A TOGGLE timeout was detected.
Check the statuses of monitor LEDs on the front panel of the board by referring to the operation manual for the field network board.
D5B Fieldbus error (Access-privilege retry over) An access-privilege retry over error was detected.
Check the statuses of monitor LEDs on the front panel of the board by referring to the operation manual for the field network board.
D5C Fieldbus error (Access-privilege open error) An access-privilege open error was detected.
Check the statuses of monitor LEDs on the front panel of the board by referring to the operation manual for the field network board.
D5D Fieldbus error (FBRS link error) A FBRS link error was detected.
Check the statuses of monitor LEDs on the front panel of the board by referring to the operation manual for the field network board.
D5E Fieldbus error (Mailbox response) A mailbox response error was detected.
Check the statuses of monitor LEDs on the front panel of the board by referring to the operation manual for the field network board.
D60 Expanded-SIO 2/4 CH isolation power error An Expanded-SIO isolation power error was detected. D61 Expanded-SIO 1/3 CH isolation power error An Expanded-SIO isolation power error was detected.
D62 Expanded-SIO baud-rate-generator clock oscillation error An Expanded-SIO clock oscillation error was detected. D63 Expanded-SIO UART paging error An Expanded-SIO paging error was detected.
D64 Expanded-SIO assignment error The “board channel assignment number” or “expanded-I/O slot assignment
number” in I/O parameter Nos. 100, 102, 104, 106, 108 or 110 may be outside the input range or duplicated, a serial communication expansion board may not be installed in the specified slot, or a “communication mode” other than RS232C may have been selected when the “board channel assignment number” is other than “1” or “2,” among other reasons.
D67 Motor/encoder configuration information mismatch error The “motor/encoder configuration information” (motor identification number and
encoder identification number) in driver parameter No. 26 does not match the “motor/ encoder configuration information” (motor identification number and encoder identification number) in encoder parameter No. 11. Check the parameter values, encoder cable connection, etc.
D5F Network I/F Module Type Mismatch Error The network I/F module type set in I/O Parameter No. 225 and the network
module type actually mounted do not match with each other. ĺ&KHFNWKHVHWWLQJVVXFKDVWKHYDOXHLQ,23DUDPHWHU1RDQGWKH
network module actually mounted.
Appendix

IAI XSEL Specifications

General

Type	Controller
Power Supply	24V DC
Communication	Ethernet, RS-232
Communication Interface	Ethernet
Operating Temperature	0 to 50 °C
Weight	Varies depending on model. Consult datasheet.
