Part 1 Installation Chapter 5 Specifications.
Part 1 Installation
249
265
081 681 591
49.5757549.5
125.3
5
-3
5
(80)
3
269
285
081 681
591
59 . 5757559 . 5
5
-3
5
4. External Dimensions
4.1 P/Q/PCT/QCT Type (Three-phase Standard Specification, Single-phase Global Specification,
Single-phase Standard Specification) 4-axis Controller
External views of enclosures for various 4-axis controllers are shown below (the external enclosure
dimensions are the same for 1-axis to 4-axis controllers).
Fig. 4-1 P/Q/PCT/QCT Type 4-axis Controller (Incremental Specification) (Three-phase Standard
Specification, Single-phase Global Specification, Single-phase Standard Specification)
Fig. 4-2 P/Q/PCT/QCT Type 4-axis Controller with Absolute Brake Unit (Three-phase Standard
Specification, Single-phase Global Specification, Single-phase Standard Specification)
