Part 1 InstallationChapter 5 Specifications.
Part 1 Installation
(3) Calculating the wattage of each actuator that can be connected to a single-phase specification system
For LSA (Linear Actuator) and DD (Direct Drive Motor) to connect to the single phase type, calculate the
wattage from “Output for controller wattage calculation” in the table below.
Also, make selection to have the total wattage of LSA, DD and other actuators at 1600W or less.
1600W ≥ LSA Total wattage of LSAs (Output for controller wattage calculation × Number of axes) + Wattage
of DD (Output for controller wattage calculation) + Wattage of other actuators (Motor wattage × Number of
axes)
Wattage Calculation Table for LSA and DD in Single Phase Type
Actuator model
number
Corresponding
driver output
[W]
Number of sliders
[unit]
Output for controller
wattage calculation
[W]
Remarks
S6SS 100 1 300
S6SM 100 2 600
S8SS 100 1 300
S8SM 100 2 600
S8HS 100 1 300
S8HM 100 2 600
S10SS 100 1 300
S10SM 100 2 600
S10HS 200 1 600
S10HM 200 2 1200
H8SS/L15SS 200 1 600
H8SM/L15SM 200 2 1200
H8HS 200 1 600
H8HM 200 2 1200
N15SS 200 1 600
N15SM 200 2 1200
N15HS 200 1 600
N15HM 200 2 1200
N19SS 300 1 600
W21SS 400 1 800
W21SM 400 2 1600
W21HS 1000 1 1500
W21HM 1000 2 3000
Cannot be used.
DD (LT18S, T18S)
200
－
600
DD (LH18S, H18S) 600
－
1200

IAI XSEL Specifications

General

Type	Controller
Power Supply	24V DC
Communication	Ethernet, RS-232
Communication Interface	Ethernet
Operating Temperature	0 to 50 °C
Weight	Varies depending on model. Consult datasheet.
