The Feature Code #5763 DVD Drive Assembly has a SATA to USB interface card that is attached to the rear of the drive. For
customers who require front-end access when attaching a DVD-RAM drive to their POWER or PureFlex system, an internal USB
cable port is provided near the front of the drive. The front port requires an external USB cable in order to attach the drive to
the IBM POWER System. See Figure 5.
Note: Feature Code #5763 does not allow a second DVD drive Feature Code #5757 to be added.
Figure 5. FC 5763 is designed for customers who require front-end connection of their DVD-RAM drive. Available
only on the IBM 7226.
Loading and Unloading a DVD Disc
Loading a DVD
Unloading a Disc
Loading a DVD
Use the following instructions to load or unload a DVD disc.
Note: When loading a disc, make sure that the text on the disc faces up.
To load a disc:
1. Press the load/unload button to eject the disc tray (see Figure 1).
2. Press the disc onto the spindle on the disc tray.
3. Gently push the disc tray completely into the disc opening.
Unloading a Disc
To unload a disc:
1. Press the load/unload button to eject the disc tray.
2. Remove the disc from the disc tray.
3. Gently push the disc tray completely into the disc opening.
If the disc fails to eject, refer to the procedure for manually removing a disc in Manually Removing a DVD Disc from the Drive .
