Table 5. Firmware Error Codes. (continued)
Error Code Description Action/
Possible Failing FRU
2602 0014 A PCI adapter is not properly seated, or an
invalid type of adapter is installed in the system
v If the location code identifies a slot:
1. Check the PCI adapter specified by the
location code for proper seating.
2. Verify that the PCI adapter specified by
the location code is supported on this
system.
3. Replace the adapter.
v
If the location code identifies an I/O planar:
1. Check for system firmware updates. Apply
the update if one is available.
2. Replace the I/O planar.
2602 0Fxy PCI bridge chip failure Replace the system backplane, location:
U0.1-P1.
2680 0Axy MX-PCI bridge BIST failure The problem is associated with bridge ″y″ in I/O
drawer ″x.″
Replace the I/O backplane in I/O drawer ″x.″
Location U0.x-P1
See “Determining Location Code” on page 161
or location code information related to this error.
2680 0Cxx Machine check occurred
1. Replace the part identified by the location
code associated with this error code.
2. If the location code associated with this error
code identifies an adapter, and replacing the
adapter does not correct the problem,
replace the CEC backplane or I/O planer,
location:
U0.1-P1 or U0.dd-P1
2680 0Dxx Machine check occurred; unable to isolate to a
single device
Go to “MAP 1540: Problem Isolation Procedures”
on page 110
27A0 0001 Error obtaining external RIO cable IDs
1. Check the SPCN and RIO cabling going to
the I/O subsystem specified by the location
code.
2. Check for system firmware updates.
3. Replace the I/O subsystem planar specified
by the location code.
2803 0xxx Description: Real-time-clock (RTC) errors
Action:
1. Errors reported against the real-time clock can be caused by low battery voltage and (more
rarely) power outages that occur during normal system usage. These errors are warnings that
the real-time clock data content needs to be re-established and do not require any FRU
replacement unless the error is persistent. When one of these errors occurs, the time and date
information has been lost.
To set/restore the time and date, use the operating system facility.
2. If the error is persistent, replace the battery.
Location: U0.1-P1-X1-V4
3. If the error is persistent after the battery is replaced, replace the service processor.
Location:
U0.1-P1-X1
188 EserverpSeries 615 Service Guide
