IBM P 615 series

AIX and Physical Location Code Table
Note: AIX location codes are not available when using the LINUX operating system.
The following table contains AIX and physical location codes for the pSeries 615 Model 6C3 and Model
6E3.
Component Name Physical Location Code AIX Location Code
System Unit Backplane
Rack Frame U0
System Unit Drawer U0.1
System Backplane U0.1-P1
IDE Controller U0.1-P1-X1/Q6 1G-19
IDE Optical Drive U0.1-P1-X1/Q6-A0 1G-19-00
Other Optical Drive U0.1-P1-X1/Q6-A1 1G-19-01
PHB2 U0.1-P1 1Y-10, 1Y-12, 1Y-13, 1Y-14, 1Y-16
EADS_X under PHB0 U0.1-P1
PHB1 U0.1-P1
EADS_X under PHB1 U0.1-P1 1G-10, 1G-12, 1G-14, 1G-16
Service Processor Card U0.1-P1-X1
DASD Backplane (Right) U0.1-P2
DASD Backplane (Left) U0.1-P3
Media Backplane U0.1-P4
SCSI RAID Card U0.1-P5
Memory DIMMs
Memory
DIMM
1 J3B
U0.1-P1-M1
Memory
DIMM
2 J3A
U0.1-P1-M2
Memory
DIMM
3 J2B
U0.1-P1-M3
Memory
DIMM
4 J2A
U0.1-P1-M4
Memory
DIMM
5 J0A
U0.1-P1-M5
Memory
DIMM
6 J0B
U0.1-P1-M6
Memory
DIMM
7 J1A
U0.1-P1-M7
Memory
DIMM
8 J1B
U0.1-P1-M8
System Backplane Integrated Devices
Debug Connector
(Manufacturing
Use Only)
Labeled Debug Connector
Parallel Port U0.1-P1-X1/R1 01-R1
ISA Bus U0.1-P1-X1 1G-18
30 EserverpSeries 615 Service Guide
