IBM P 615 series

Service Processor Checkpoints
Service processor checkpoints are in the range 8xxx to Bxxx. The message OK indicates successful
service processor testing and initialization. Firmware checkpoints are listed in “Firmware Checkpoints” on
page 140.
Note: A spinning (or twirling) slash displays in the upper-right corner of the operator panel display while
some checkpoints are being displayed. If the slash stops spinning, a hang condition is indicated.
Table 1. Service Processor Checkpoints
Checkpoint Description Action/
Possible Failing FRU
8000 Test of the service processor DRAM See note 1 on page 138.
8004 Verify base code checksum See note 1 on page 138.
8008 Verify base code mirror checksum See note 1 on page 138.
8009 Set NVRAM configuration in TITAN See note 1 on page 138.
800F Start base code See note 1 on page 138.
8010 Start supervisor in base code See note 1 on page 138.
8012 Initialize hardware interrupts See note 1 on page 138.
8014 Allocate and initialize area in DRAM See note 1 on page 138.
8016 Initialize debugger and build VPD See note 1 on page 138.
8018 Initialize service processor interfaces See note 1 on page 138.
801A Initialize external FLASH load See note 1 on page 138.
801B Initialize and test ISA hub chip See note 1 on page 138.
801C Initialize and test SUPER I/O chip See note 1 on page 138.
801F Initialize diskette, verify VDASD and start
operational loader
See note 1 on page 138.
809x Related to recovery mode system firmware
update from diskette
See note 3 on page 138.
8092 Diskette initialization during recovery mode
system firmware update
See note 3 on page 138.
8098 Firmware image being read during recovery
mode system firmware update
See note 3 on page 138.
809C Firmware image being written during
recovery mode system firmware update
See note 3 on page 138.
809F Diskette error during recovery mode system
firmware update
See note 3 on page 138.
8100 Start operational loader See note 1 on page 138.
81xx Load code into DRAM from VDASD (where
xx = number of loads)
See note 1 on page 138.
81FE Load service processor operating system See note 1 on page 138.
81FF Start service processor operating system See note 1 on page 138.
9000 Primary service processor task initializing See note 1 on page 138.
9009 System processor IPL has started See note 1 on page 138.
9010 Primary service processor thread waiting
for response
See note 1 on page 138.
9020 Service processor state set to pre-standby See note 1 on page 138.
Chapter 4. Checkpoints 133
