Firmware
Checkpoints
Firmware
uses
checkpoints
(progress
codes)
in
the
range
of
Exxx
to
EFFF.
These
checkpoints
occur
during
system
startup
and
can
be
useful
in
diagnosing
certain
problems.
Service
processor
checkpoints
are
listed
in
“Service
Processor
Checkpoints”
on
page
133.
If
you
have
a
checkpoint
with
no
location
code
associated
with
it,
see
“Determining
Location
Code”
on
page
161.
If
a
checkpoint
has
a
location
code
associated
with
a
FRU
replacement,
see
“Mapping
AIX
and
Physical
Location
Codes”
on
page
28
for
physical
location
information.
If
you
replace
FRUs
and
the
problem
is
still
not
corrected,
go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110
unless
otherwise
indicated
in
the
tables.
Note:
If
you
receive
a
four-digit
code
in
the
range
of
E1xx
to
EFFF
that
is
not
listed
in
the
table
above,
go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
Table
2.
Firmware
Checkpoints
Checkpoint
Description
Action/
Possible
Failing
FRU
E101
Create
RTAS
node
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E102
Load/Init
RTAS
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E105
Transfer
control
to
operating
system
(normal
boot).
See
“Boot
Problems/Concerns”
on
page
155.
E10A
Load
RTAS
device
tree
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E10B
Set
RTAS
device
properties
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E111
GOOD
CRC
-
jump
to
composite
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E120
Initialize
I/O
and
early
memory
block
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E121
Initialize
service
processor
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E122
RTAS
sensor
setup
complete
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E130
Build
device
tree
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E131
Build
device
tree
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E132
Build
device
tree
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E133
Build
device
tree
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E135
Configuring
memory
nodes
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E134
Create
memory
node
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
E138
Create
options
node
Go
to
“MAP
1540:
Problem
Isolation
Procedures”
on
page
110.
140
EserverpSeries
615
Service
Guide
