Appendix D. Setting Up the System Rack
Before setting up a rack, check through the following specifications and clearances, then go to “Model 6C3
Rack Installation Inventory” on page 405.
Rack Specifications
This section contains specifications for the system rack.
7014 Model T00 and T42 Rack
The mechanical packaging, cooling, power supply, and environmental specifications for the rack are shown
in the following table:
Dimensions
Height 1804 mm 71.0 in.
Capacity 36 EIA Units
With PDP - DC only 1926 mm 75.8 in.
Width without side
panels
623 mm 24.5 in.
With side panels 644 mm 25.4 in.
Depth with rear door 1042 mm 41.0 in.
RS/6000 T00 with
both doors
1098 mm 43.3 in.
pSeries T00 with both
doors
1147 mm 45.2 in.
Weight
Base Rack 244 kg 535 lbs
Full Rack¹ 816 kg 1795 lbs.
Electrical² (sum specified values for
drawers
or enclosures in rack)
AC Rack
Power source loading
maximum in kVA (per
PDB)⁴
4.8
Voltage range (V ac) 200 to 240
Frequency (hertz) 50 or 60
Temperature
Requirements
(see specifications for drawers or enclosures)
Humidity
Requirements
(see specifications for drawers or enclosures)
Noise Emissions (see specifications for drawers or enclosures)
Clearances Front Back Left Right
Install/Air Flow Maintenance of a proper service clearance should allow proper airflow.
Service 915mm(36 in) 915mm(36 in) 915mm(36 in) 915mm(36 in)
1. Configuration dependent, base rack weight plus the weight of the drawers mounted in the rack. The rack can
support up to a maximum weight of 35 lbs/EIA Unit.
2. The total rack power should be derived from the sum of the power used by the drawers in the rack.
3. Each AC Power Distribution Bus (PDB) can supply 4.8 kVA. A rack can have up to four PDB’s as required by the
drawers mounted in the rack.
403
