Fan

Locations

(Model

6C3

and

Model

6E3)

The

following

illustration

identifies

the

system

cooling

fans.

Each

fan

has

one

green

LED

and

one

amber

LED

located

on

top

of

the

fan.

A

lit

amber

LED

indicates

that

the

fan

is

not

operating

correctly.

1

2

3

4

1

Cooling

Fan

1

3

Cooling

Fan

3

2

Cooling

Fan

2

4

System

Unit

14

EserverpSeries

615

Service

Guide
