Power
Supply
Locations
(Model
6C3
and
Model
6E3)
Each
power
supply
has
three
LEDs.
The
amber
LED
on
the
power
supply
indicates
a
problem
with
the
power
supply.
If
a
power
supply
is
diagnosed
with
a
cooling
problem,
the
entire
power
supply
must
be
replaced.
1
2
3
4
5
6
7
1
Primary
Power
Supply
V2
4
System
Unit
(In
Service
Position)
2
Redundant
Power
Supply
V1
5
Fault
LED
(Amber)
3
Power
Supply
Filler
(Required
in
place
of
redundant
power
supply)
6
DC
Good
LED
(Green)
7
AC
Good
LED
(Green)
Chapter
1.
Reference
Information
13
