Component Name Physical Location Code AIX Location Code
HMC1 Connector U0.1-P1-X1/S4
HMC2 Connector U0.1-P1-X1/S5
SPCN Connector1 (SPCN Port0) U0.1-P1-X1/Q4
SPCN Connector2 (SPCN Port1) U0.1-P1-X1/Q5
Keyboard Port U0.1-P1-X1/K1 01-K1-00
Keyboard U0.1-P1-X1/K1-K1 01-K1-00-00
Mouse Port U0.1-P1-X1/O1 01-K1-01
Mouse U0.1-P1-X1/O1-O1 01-K1-01-00
Ethernet #1 Controller U0.1-P1/E1 1L-08
Ethernet #2 Controller 1Gb U0.1-P1/E2 1j-08
Rack Indicator Connector U0.1-P1/Q1
Serial Connector S1F
(Located
on Operator Panel)
U0.1-P1-X1/S1 01-S1
Serial Port 1 U0.1-P1-X1/S1 01-S1
Serial Port 2 U0.1-P1-X1/S2 01-S2
Serial Port 3 U0.1-P1-X1/S3 01-S3
Diskette Port U0.1-P1-X1/D1 01-D1
Diskette Drive U0.1-P1-X1-D1 01-D1-00-00
Pluggable Adapters
PCI Slot 1 U0.1-P1/I1
PCI Slot 1 Card U0.1-P1-I1 1Z-08
PCI Slot 2 U0.1-P1/I2
PCI Slot 2 Card U0.1-P1-I2 1c-08
PCI Slot 3 U0.1-P1/I3
PCI Slot 3 Card U0.1-P1-I3 1f-08
PCI Slot 4 U0.1-P1/I4
PCI Slot 4 Card U0.1-P1-I4 1n-08
PCI Slot 5 U0.1-P1/I5
PCI Slot 5 Card U0.1-P1-I5 1H-08
PCI Slot 6 U0.1-P1/I6
PCI Slot 6 Card U0.1-P1-I6 1V-08
SCSI Controller for Internal DASD U0.1-P1/Z1 1S-08-00
SCSI Controller for Internal devices U0.1-P1/Z2 1S-08-01
Disk Drive 1 (in backplane on right) U0.1-P1/Z1-A3 1S-08-00-3,0
Disk Drive 2 (in backplane on right) U0.1-P1/Z1-A4 1S-08-00-4,0
Disk Drive 3 (in backplane on right) U0.1-P1/Z1-A5 1S-08-00-5,0
Disk Drive 4 (in backplane on right) U0.1-P1/Z1-A8 1S-08-00-8,0
SES for SCSI bus 0 (in backplane on
right)
U0.1-P1/Z1-Af 1S-08-00-15,0
Disk Drive 5 (in backplane on left) U0.1-P1/Z2-A3 1S-08-01-3,0
Disk Drive 6 (in backplane on left) U0.1-P1/Z2-A4 1S-08-01-4,0
Chapter 1. Reference Information 31
