IBM P 615 series User Manual

Component Name Physical Location Code AIX Location Code
Disk Drive 7 (in backplane on left) U0.1-P1/Z2-A5 1S-08-01-5,0
Disk Drive 8 (in backplane on left) U0.1-P1/Z2-A8 1S-08-01-8,0
SES for SCSI bus 1 (in backplane on
left)
U0.1-P1/Z2-Af 1S-08-01-15,0
Media Device 1 (for example, SCSI
Tape, DVD)
U0.1-P1/Z2-A0
Fans
System Cooling Fan 1 U0.1-F1
System Cooling Fan 2 U0.1-F2
System Cooling Fan 3 U0.1-F3
Operator Panel
CEC Operator panel U0.1-L1
System VPD module U0.1-L1-N1
Temperature Sensor (on Operator
Panel)
U0.1-L1
Time-of-Day Clock (TOD) U0.1-P1-X1
Power Supply
Power supply V1 (Redundant) U0.1-V1
Power supply V2 (Primary) U0.1-V2
Voltage Regulator Module - 1.2V U0.1-P1-V3
Voltage Regulator Module - 2.5V U0.1-P1-V2
Voltage Regulator Module - 1.8V U0.1-P1-V1
Battery
Battery U0.1-P1-X1-V4
Platform Firmware
Platform Firmware U0.1-P1-X1/Y1
Notes:
1. The physical location code for the PCI slots, when empty, uses the P1/Ix notation, where the ’/’ identifies an
integrated device (in this case the empty slot). A PCI device plugged into the slot uses the P1-Ix notation, where
the ’-’ identifies a plugged device.
2. The SCSI bus IDs are the recommended values. The SCSI IDs shown for media devices indicate how the
devices are set when they are shipped from the factory. Field installations may not comply with these
recommendations.
32 EserverpSeries 615 Service Guide
