Table 9. Common Firmware Error Codes (continued)
Error Code Description Action/
Possible Failing FRU
B1xx 4633 System power control (SPCN) network failure
This error code may be informational, or it may indicate a failure in the SPCN firmware update.
Before changing any parts, examine word 13 in the service processor error log entry, or bytes 68
and 69 in the AIX error log entry. For detailed instructions on finding word 13 in the service
processor error log entry, or bytes 68 and 69 in the AIX error log entry, refer to error code B1xx
4699 in this service guide.
All of the following values of word 13 (or bytes 68 and 69) indicate a failure of an SPCN firmware
update:
A701
A702
A703
A704
A705
A706
A707
For these values of word 13, do the following:
1. Power down the system.
2. Collect the service processor error log data for the B1xx 4633 error. From the main service
processor menu, enter 3 to access the ″System Information menu. Select option 3, ″Service
Processor Error Logs″.
3. Collect the SPCN trace data. From the main service processor menu, enter 3 to access the
″System Information menu. Select option 9, the ″Power Control Network Utilities Menu″. Then
select option 4, ″Collect and Display the SPCN Trace Data″.
4. Power on the system.
5. Wait 10 minutes after the system has reached the AIX prompt. Look at the AIX error log for new
B1xx 4633 errors with the word 13 values (in bytes 68 and 69 in the error log entry). If there
are no B1xx 4633 errors with matching timestamps, the SPCN down load was successful. If the
download failed again (there is another B1xx 4633 error in the AIX error log with the correct
timestamp), do the following:
a. Power down the system.
b. Collect the service processor error log data for the B1xx 4633 error (see step 2 above).
c. Collect the SPCN trace data (see step 3 above).
d. Contact service support.
For
all other values of word 13, or bytes 68 and 69, do the following:
1. Check for system firmware updates. Apply if available.
2. Call service support.
B1xx 4634 SPCN loop fault Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
B1xx 4643 I2C card/flex cable detection error Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
B1xx 4644 Processor VPD system fault Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
B1xx 4645 I2C (Non-processor) VPD System Fault Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
B1xx 4646 General VPD fault Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
B1xx 4647 Write TM field in system VPD Replace the operator panel, location: U0.1-L1.
Chapter 5. Error Code to FRU Index 205
