8. Lift the power supply release handles until they are perpendicular (90 degrees) to the top of the power
supply. By placing the handles perpendicular to the top of the power supply, the base or hinged portion
of each handle acts as a cam and helps pry the power supply from its connector located on the
system backplane.
1
2
3
5
4
1
2
3
5
4
3
1 Service Access Cover 4 Power Supply #1 (Primary)
2 Power Supply Filler Panel 5 Power Supply Release Handle
3 System
9. After the power supply is released from its connector, pull the power supply straight out from the
system.
350 EserverpSeries 615 Service Guide
