Amber LEDs indicate a fault or identify condition. If your system or one of the components in your system
has an amber LED turned on or blinking, identify the problem and take the appropriate action to restore
the system to normal.
The following table identifies the location, color and status of your system component LEDs.
Unit
(FRU)
LED
Function
Location Viewable
Location
LED
Color
OFF ON Blink
Power and Packaging LEDs
System
Attention Operator
Panel and
Rear
External
Front and
Rear
Amber Normal Fault Identify
Power¹ Green No ac System On Standby
Fan Identify¹ Part Internal Amber Normal N/A Identify
Power Supply
AC Input
Good¹
Part External Green No Input Input Good N/A
Fault¹
/Identify
Part External Amber Normal Fault 1. Identify
2.Comm.
Fault
DC Output
Good
Part External Green
All Pwr Sup
Outs Off
All PS
Outputs On
Blinj if PS
micro or comm
link failed
Disk Drives
(DASD)
Power¹ DASD Cage Chassis Green Off Power N/A
Activity¹ DASD can Chassis Green No Activity N/A Activity
Activity
Repl
DASD can Chassis Amber Meets RPA Hot-Swap Requirement
Unit
(FRU)
LED
Function
Location Viewable
Location
LED
Color
OFF ON Blink
CARD LEDs
PCI Slots
Power¹ Socket External Green PCI Hot-Swap Standards
Identify Socket External ³ Amber PCI Hot-Swap Standards
RIO-G Identify Socket External Amber Normal N/A Identify
Memory DIMMs Identify
Memory
Connector
Internal Only Amber Normal N/A Identify
System
Backplane
Identify
Planar Internal Only Amber Normal N/A Identify
DASD
Backplane
Identify Card Internal Amber Normal N/A Identify
Media
Backplane
Identify Card Internal Amber Normal N/A Identify
Service
Processor Card
Identify
Card Internal Amber Normal N/A Identify
Voltage
Regulator
Module
Identify
Card Internal Amber Normal N/A Identify
RAID Daughter
Card
Identify
Card External Amber Normal N/A Identify
390 EserverpSeries 615 Service Guide
