IBM P 615 series User Manual

1. Attach the four blue wheel-shaped knobs at the points indicated in the following figure:
2
1
2. Using three persons, grasp the handles located on each side of the system drawer, and lift the system
drawer onto the extended rails. Align the three screw holes in the inner rails with the screw holes in the
sides of the system drawer.
3. Using the six rail-to-system retaining screws, three on each side, mount the inner rails to each side of
the system drawer. Tighten each of the screws with a screwdriver or similar tool.
1
2
3
1 Rack Enclosure 3 Rail-to-system retaining screws
2 System Rail Assembly
4. Simultaneously depress the safety latches, located on each system rail assembly, and push the system
into the rack.
Appendix D. Setting Up the System 415
