All of the system POST indicators are displayed on the
system console, the system pauses and then restarts. The
term POST indicators refers to the device mnemonics (the
words memory, keyboard, network, scsi, and speaker) that
appear on the system console during the power-on self-test
(POST).
Go to “Boot Problems/Concerns” on page 155.
The system stops and all of the POST indicators are
displayed on the system console. The term POST indicators
refers to the device mnemonics (the words memory, keyboard,
network, scsi, and speaker) that appear on the system
console during the power-on self-test (POST).
Go to “Boot Problems/Concerns” on page 155.
The system stops and the message STARTING SOFTWARE
PLEASE WAIT... is displayed on the firmware console.
Go to Chapter 4, “Checkpoints,” on page 131.
The system does not respond to the password being entered
or the system login prompt is displayed when booting in
service mode.
1. If the password is being entered from the
Hardware Management Console (HMC), go to the
Hardware Management Console Maintenance
Guide.
2. If the password is being entered from a keyboard
attached to the system, the keyboard or its
controller may be faulty. In this case, replace
these parts in the following order:
a. Keyboard
b. Service processor, location: U0.1-P1-X1. (See
notes on page 53).
3.
If the password is being entered from an ASCII
terminal, use the problem determination
procedures for the ASCII terminal. Make sure the
ASCII terminal is connected to S1.
If the problem persists, replace the service
processor, location: U0.1-P1-X1. (See notes on
page 53).
If
the problem is fixed, go to ″MAP 0410: Repair
Checkout″, in the RS/6000 Eserver pSeries
Diagnostic Information for Multiple Bus Systems.
If the problem is still not corrected, go to “MAP 1548:
Processor Subsystem Problem Isolation” on page 113.
No codes are displayed on the operator panel within a few
seconds of turning on the system. The operator panel is
blank before the system is powered on.
Reseat the operator panel cable. If the problem is not
resolved, replace in the following order:
1. Operator panel assembly, location: U0.1-L1. Swap
the VPD module from the old operator panel to
the new operator panel.
2. Service processor, location: U0.1-P1-X1. (See
notes on 53).
If
the problem is fixed, go to ″MAP 0410: Repair
Checkout″, in the RS/6000 Eserver pSeries
Diagnostic Information for Multiple Bus Systems.
If the problem is still not corrected, go to “MAP 1548:
Processor Subsystem Problem Isolation” on page 113.
60 EserverpSeries 615 Service Guide
