IBM PPC750FX User Manual

Evaluation Board Manual
PPC750FX Evaluation Board Preliminary
CPLD Programming
Page 98 of 115
750FXebm_ch11.fm
June 10, 2003
flash_n/sram_sel small_flash_cs_n 5.300 5.300
flash_n/sram_sel small_flash_hi_cs_n 5.300 5.300
flash_n/sram_sel sram_cs_n 5.300 5.300
flash_n/sram_sel sram_hi_cs_n 5.300 5.300
flash_n/sram_sel textpin_d 5.500 5.500
ignore_fans_n led_red_n 5.100 5.100
ignore_fans_n NOFAN_N 5.100 5.100
initact cpu_trst_n 13.900 13.900
initact cpu0_hreset_n 11.000 10.200
initact cpu1_hreset_n 14.300 13.900
lcs_n[0] big_flash_cs_n 5.200 5.200
lcs_n[0] small_flash_cs_n 5.200 5.200
lcs_n[0] small_flash_hi_cs_n 5.200 5.200
lcs_n[0] sram_cs_n 5.200 5.200
lcs_n[0] sram_hi_cs_n 5.200 5.200
lcs_n[0] textpin_d 5.400 5.400
lcs_n[1] dev_adr[0] 8.500 8.500
lcs_n[1] dev_adr[1] 8.500 8.500
lcs_n[1] dev_adr[2] 8.500 8.500
lcs_n[1] dev_adr[3] 8.500 8.500
lcs_n[1] dev_adr[4] 8.500 8.500
lcs_n[1] dev_adr[5] 8.500 8.500
lcs_n[1] dev_adr[6] 8.500 8.500
lcs_n[1] dev_adr[7] 8.500 8.500
lcs_n[1] fpga_cs_n 5.400 5.400
lcs_n[2] uart_cs_n 5.000 5.000
lcs_n[2] write_n 5.800 5.800
lcs_n[3] nvram_cs_n 15.300 15.300
lcs_n[3] uart_cs_n 6.600 6.600
lcs_n[3] write_n 7.400 5.100
ldev_addr[19] small_flash_cs_n 5.200 5.200
ldev_addr[19] small_flash_hi_cs_n 5.200 5.200
ldev_addr[19] sram_cs_n 5.200 5.200
ldev_addr[19] sram_hi_cs_n 5.200 5.200
ldev_addr[19] textpin_d 5.400 5.400
ldev_addr[20] small_flash_cs_n 5.200 5.200
ldev_addr[20] small_flash_hi_cs_n 5.200 5.200
Table 11-6. Pin-to-Pin Signal Delay (Continued)
Source Destination Longest Delay (ns) Shortest Delay (ns)
