This ends the procedure.
24. Have you swapped all the regulator card assemblies?
No Go to step 25.
Yes This ends the procedure. Go to ″Map 0410: Repair Checkout″ in the
Diagnostic Information for Multiple Bus Systems.
25. Perform the following:
a. Power off the system.
b. Remove the new regulator assembly and install the original regulator assembly.
c. Go to step 23 on page 108 to test another regulator assembly.
Reference Code The Possible Failing Regulators are:
1201, 1401 R01, R02, R06-R10 Programmable Regulator Assembly
1202, 1402 R01, R02, R06-R10 Programmable Regulator Assembly
1203, 1204, 1403, 1404 R04, R05, R06 Memory Regulator Assembly
1205, 1206, 1405, 1406 R01, R02, R06-R10 Programmable Regulator Assembly
Chapter 3. Maintenance Analysis Procedures
109
