Examples For Using the Generic Sample Modem Configuration Files
Modem Setup Z Setup Z0
(Rare)
Setup F Setup F0 Setup F1
AT&T DataPort 2001 ** X
Bocamodem 1440E X
Hayes Smart Modem
300
X
IBM 5841 X
IBM 5843 X
IBM 7851 X
IBM 7852-10 X
IBM 7855 X
USRobotics 36.6K
Sportster
X
Zoom V.32 X
Note: ** Ring interrupt only on first ring.
Customizing the Modem Configuration Files
You can create your own modem configuration file(s) or modify the samples provided.
After you customize your modem configuration files, you must access them through the
Configure Remote Maintenance Policy Service Aid rather than from the SP menus.
Note: If you have already set up your serial ports, line speeds, authorizations, and
telephone numbers from the SP menus, specify your customized modem
configuration files from the service aid.
If you have not already set up your serial ports, line speeds, authorizations, and
telephone numbers from the SP menus, you can set them up with the service aids
while you specify your customized modem configuration files.
IBM 7852-400 DIP Switch Settings
If you are using a 7852-400 modem to enable service processor communications, for
proper operation, the DIP switches must be set according to the following table.
Switch Position Function
1 Up Force DTR
2 Up Flow Control &E4
3 Down Result Codes Enabled
4 Down Modem Emulation Disabled
5 Up Auto Answer Enabled
6 Up Maximum Throughput Enabled
7 Up RTS Normal Functions
8 Down Enable Command Mode
Appendix G. Modem Configurations
621
