System with One I/O Drawer, and Two H50 and H70s Sharing the I/O Rack
Primary I/O Drawer in Top Position
Note: Ensure that the cables from the I/O drawer are tied to the sides of the rack to
enable servicing of the system drawers installed under the I/O drawers.
Follow the installation instructions for each system when the I/O rack is shared between
two system configuration types.
First System with Primary I/O Drawer
Installed in Top Position of the
I/O Rack
Third System Drawer
Installed Under
Second System Drawer
Second System Drawer
Installed under
Primary I/O Drawer
Disk Drive Drawer
Installed Under
Third System Drawer
14 Service Guide
