IBM S85 pSeries 680 User Manual

I/O Drawer 0 Locations
FRU Name Slot
Name
Location Code AIX Location
Code
Physical
Connection
Logical
Connection
I/O drawer 0 (of
0to3)
U0.1
I/O Planar U0.1-P1
RIO Controller 0 U0.1-P1 00-00
PCI Controller 1 U0.1-P1 00-f850-0000
PCI slot 1 U0.1-P1-I1 20-58 or
20-58 to
20-5F or
2B-XX
I/O Planar J13,
64 bit slot
PCI Controller
1
PCI slot 2 U0.1-P1-I2 20-60 or
20-60 to
20-67 or
2C-XX
I/O Planar J4,
32 bit slot
PCI Controller
1
PCI slot 3 U0.1-P1-I3 20-68 or
20-68 to
20-6F or
2D-XX
I/O Planar J5,
32 bit slot
PCI Controller
1
PCI slot 4 U0.1-P1-I4 20-70 or
20-70 to
20-77 or
2E-XX
I/O Planar J6,
32 bit slot
PCI Controller
1
PCI Controller 0 U0.1-P1 00-f840-0000
PCI slot 5 U0.1-P1-I5 10-58 or
10-58 to
10-5F or
1B-XX
I/O Planar J14,
64 bit slot
PCI Controller
0
PCI slot 6 U0.1-P1-I6 10-60 or
10-60 to
10-67 or
1C-XX
I/O Planar J7,
32 bit slot
PCI Controller
0
PCI slot 7 U0.1-P1-I7 10-68 or
10-68 to
10-6F or
1D-XX
I/O Planar J8,
32 bit slot
PCI Controller
0
PCI slot 8 Service
Processor
U0.1-P1-X1 10-70 or
10-70 to
10-77 or
1E-XX (not
used by AIX)
I/O Planar J9,
32 bit slot
PCI Controller
0
TOD U0.1-P1-X1 Not used by
AIX
On Service
Processor
BOOT U0.1-P1-X1 Not used by
AIX
On Service
Processor
Chapter 1. Reference Information
53
