FRU Name Slot
Name
Location Code AIX Location
Code
Physical
Connection
Logical
Connection
JTAG U0.1-P1-X1 Not used by
AIX
On Service
Processor
VDISK U0.1-P1-X1 Not used by
AIX
On Service
Processor
NVRAM U0.1-P1-X1 Not used by
AIX
On Service
Processor
PCI slot 8,
Service Processor
ISA Bridge
U0.1-P1-X1 10-78 or
10-78 to 10-7f
or 1F-XX (not
used by AIX)
I/O Planar J9,
32 bit slot
PCI Controller
0
PCI slot 8 Real
Time Clock (RTC)
U0.1-P1-X1 Not used by
AIX
On Service
Processor
I/O ASIC SIO
PCI slot 8 Timer U0.1-P1-X1 Not used by
AIX
On Service
Processor
I/O ASIC SIO
Interrupt
Controller
U0.1-P1-X1 Not used by
AIX
On Service
Processor
I/O ASIC
DMA Controller U0.1-P1-X1 Not used by
AIX
On Service
Processor
I/O ASIC
Diskette
Controller and
Connector
U0.1-P1-X1/D1 01-D1 On Service
Processor
Diskette Drive U0.1-P1-X1-D1 01-D1-00-00 On Service
Processor
Keyboard Mouse
Controller and
Connector
U0.1-P1-X1/K1 01-K1 On Service
Processor
Keyboard U0.1-P1-X1-K1 01-K1-00-00 On Service
Processor
Mouse Controller
and Connector
U0.1-P1-X1/O1 01-K1-01 On Service
Processor
Mouse U0.1-P1-X1-O1 01-K1-01-00 On Service
Processor
Parallel Port U0.1-P1-X1/R1 01-R1 On Service
Processor
Serial Port 1 U0.1-P1-X1/S1 01-S1 On Service
Processor
Serial Port 2 U0.1-P1-X1/S2 01-S2 On Service
Processor
system rack
Operator Panel
Cable
Service
Processor J17
PCI Controller 3 U0.1-P1 00-f870-0000
54 Service Guide
