System with Two I/O Drawers and H50 and H70 Sharing the I/O Rack
Primary I/O Drawer in Top Position
Note: Ensure that the cables from the I/O drawers are tied to the sides of the rack to
enable servicing of the system drawer installed under the secondary I/O drawers.
Follow the installation instructions for each system when the I/O rack is shared between
two system configuration types.
First System with Primary I/O Drawer
Installed in Top Position of the
I/O Rack and a Secondary I/O Drawer
Installed Below the Primary I/O Drawer
Second System Drawer
Installed Under Secondary
I/O Drawer
Secondary I/O Drawer
Disk Drive Drawer
Installed Under Second
System Drawer
12 Service Guide
