IBM S85 pSeries 680 User Manual

AIX and Physical Location Code Reference Tables
The following tables contain location codes that are used to identify functional units in
the models S80 and S85 systems. Each table below shows the locations for a physical
part of the system.
System Rack
FRU Name Slot
Name
Location Code AIX Location
Code
Physical
Connection
Logical
Connection
System Rack U1 00-00
System
Backplane
U1.1-P1 00-00
Memory
Controller
U1.1-P1 00-00 On System
Backplane
Operator Panel U1.1-P1-L1
Processor
Regulator 21
M04 U1.1-P1-V1
Processor
Regulator 22
M07 U1.1-P1-V2
I/O Hub Card M17 U1.1-P1-X1 00-00 On System
Backplane
RIO Port 0
Connector/Cable
U1.1-P1-X1/Q1
RIO Port 1
Connector/Cable
U1.1-P1-X1/Q2
RIO Port 2
Connector/Cable
U1.1-P1-X1/Q3
RIO Port 3
Connector/Cable
U1.1-P1-X1/Q4
R1 Memory Card
Quad A, Front
M01 U1.1-P1-M1 00-00 System
Backplane
R1 Memory Card
Quad A, Front
M02 U1.1-P1-M2 00-00 System
Backplane
R1 Memory Card
Quad A, Front
M03 U1.1-P1-M3 00-00 System
Backplane
R1 Memory Card
Quad B, Front
M08 U1.1-P1-M4 00-00 System
Backplane
R1 Memory Card
Quad B, Front
M09 U1.1-P1-M5 00-00 System
Backplane
R1 Memory Card
Quad B, Front
M10 U1.1-P1-M6 00-00 System
Backplane
Clock/Processor
Regulator 23
Rear
M19 U1.1-P1-X2 00-00 System
Backplane
