The SRC table name is the same as the SRC type. These tables are arranged in
hexadecimal sequence.
The URCs are arranged in hexadecimal sequence, with numeric characters listed
before alphabetic characters. For example, URCs 0001 through 0009 are listed
before URCs 000A through 000F.
Perform the action indicated in the Description/Action column of the SRC tables
beginning on page 8 to correct the problem. If this does not correct the problem,
exchange the failing items or parts in the order that they are listed in the table.
Notes:
a. When exchanging the failing items, refer to “Chapter 9. Removal and
Replacement Procedures” on page 491.
b. The failing item with the highest percent of probable cause should be
exchanged first. If exchanging the failing item with the highest percent of
probable cause does not correct the problem, reinstall the original item and
exchange the failing item with the next highest percent of probable cause.
Continue to exchange and reinstall the failing items, one at a time, until the
problem is corrected. If exchanging the failing items does not correct the
problem, ask your next level of support for assistance.
4. Go to the start of the SRC table for the SRC type.
5. Follow the instructions in the SRC table.
If you cannot find the SRC table for the SRC type, contact your next level of support for
assistance.
Table 7. SRC reference table
First Four
Characters of
SRC
Type of Code What You Should Do
0000 Operator panel reference codes Go to “(0000) Operator Panel Reference
Codes” on page 187 and follow the
instructions in the SRC table.
1xxx System power control network
(SPCN) reference codes
Go to “(1xxx) System Power Control
Network (SPCN) Reference Codes” on
page 189 and follow the instructions in
the SRC table.
A1xx Service processor reference codes Go to “(A1xx, B1xx) Service processor
Reference Codes” on page 216 and
follow the instructions in the SRC table.
B006 Common firmware reference codes Go to “(B006) Common Firmware
Reference Codes” on page 218 and
follow the instructions in the SRC table.
B1xx Service processor reference codes Go to “(A1xx, B1xx) Service processor
Reference Codes” on page 216 and
follow the instructions in the SRC table.
B4xx System processor reference codes Go to “(B4xx) System Processor
Reference Codes” on page 220 and
follow the instructions in the SRC table.
