IBM S85 pSeries 680 User Manual

Reference
Code
Description/Action
(Perform all actions before exchanging Failing
Items)
Failing Item
6018 For SRC 1011, one of the regulators (R01, R02,
or R03) has reported a fault. These are located in
the system rack.
A regulator fault was detected.
1. Programmable regulator assembly R01, R02,
or R03
Location: U1.1-P2-V1, U1.1-P2-V2,
U1.1-P2-V3
2. SPCN card
Location: U1.1-P2-X1
3. Go to “MAP 1520: Power” on page 88.
For SRC 10xC, this pertains only to the 10
EIA-unit I/O drawer in the model S80 and S85.
Both power supplies in the primary I/O drawer
failed to report power good after a power-on
command. The system will shut down. See note
on page 215.
1. Power supply 1 and 2
Location: U0.1-V1, U0.1-V2
2. Power distribution board (PDB)
Location: U0.1-X3
3. PDB J3 to I/O planar J22 cable.
4. I/O planar
Location: U0.1-P1
For SRC 10x1, this pertains only to the 10
EIA-unit I/O drawer in the model S80 and S85.
Both power supplies in a secondary I/O drawer
failed to report power good after a power-on
command. The system will shut down. See note
on page 215.
1. Power supply 1 and 2
Location: U0.x-V1, U0.x-V2 (x = I/O drawer
number 2, 3, or 4)
2. Power distribution board (PDB)
Location: U0.x-X3 (x = I/O drawer number 2,
3, or 4)
3. PDB J3 to I/O planar J22 cable.
4. I/O planar
Location: U0.x-P1 (x = I/O drawer number 2,
3, or 4)
6118 Regulator over-current fault.
One of the regulators (R01, R02, or R03) detected
an over-current condition. This may be caused by
the regulator or one of the cards powered by the
regulator.
1. Programmable regulator assembly R01, R02,
R03
Location: U1.1-P2-V1, U1.1-P2-V2,
U1.1-P2-V3
2. SPCN card
Location: U1.1-P2-X1
3. Go to “MAP 1520: Power” on page 88.
6218 Regulator over-current fault.
Regulator 1 detected an over-current condition.
This may be caused by the regulator or one of the
cards powered by the regulator.
1. Programmable regulator assembly R01
Location: U1.1-P2-V1
2. SPCN card
Location: U1.1-P2-X1
3. Go to “MAP 1520: Power” on page 88
6238 Regulator over-current fault.
Regulator 2 detected an over-current condition.
This may be caused by the regulator or one of the
cards powered by the regulator.
1. Programmable regulator assembly R02
Location: U1.1-P2-V2
2. SPCN card
Location: U1.1-P2-X1
3. Go to “MAP 1520: Power” on page 88
1xxx
Chapter 5. Error Code to FRU Index 197
