Reference Code Description/Action
Perform all actions before exchanging Failing Items
Failing Item
4509 Service processor problem isolation procedure.
1. Service processor card
Location: U0.1-P1-X1
2. Operator panel assmbly
Location: U1.1-P1-L1
4511 Service processor or system processor failure. Record
function code 19 from the operator panel. This function
code is the CCIN identifier which is used to determine
the processor or memory card type. To get the part
number for the failing card, find the CCIN number in the
parts tables under “Electronic Cards” on page 556.
1. Service processor card
Location: U0.1-P1-X1
2. Processor card 0, M08
Location: U1.1-P1-C1
3. Processor card 1, M09
Location: U1.1-P1-C2
4. Processor card 2, M20
Location: U1.1-P1-C3
4512 Clock card (in system rack) Clock Card. M07
Location: U1.1-P1-X1
4998 Operator/User Error Invalid operation
4999 Service processor firmware problem - call for support
6010 Service processor Service processor card
Location: U0.1-P1-X1
8FF0 Information only, no service action required
8FF1 System down, condition reported
A1xx, B1xx
Chapter 5. Error Code to FRU Index 217
