Ping
Select Ping from the Network Parameters menu to test a connection to a remote
system unit. After selecting the Ping option, you must choose an adapter to
communicate with the remote system.
Device Slot Hardware Address
1. Gigabit Ethernet 5: U0.1-P1-I5/E1 0004ac7c8628
2. ethernet 3: U0.1-P1-I3/E1 0060949d21db
3. token-ring 11: U0.1-P1-I11/T1 0004ac62a672
4. fddi 10: U0.1-P1-I10/Q1 00005a40aeff
.------.
|X=Exit|
′------'
(PRESS ENTER AFTER MAKING A SELECTION) ===>
After determining which adapter to use to ping the remote system, you must provide the
addresses needed to communicate with the remote system. Select the appropriate
device from the Ping menu to display a screen similar to the following:
PING IP Address
1. Client IP Address [9.3.146.162]
2. Server IP Address [9.3.146.171]
3. Gateway IP Address [0.0.0.0]
4. Subnet Mask [0.0.0.0]
.---------. .------.
|X=Execute| |X=Exit|
′---------' ′------'
===>
484 Service Guide
