Index FRU Part Number Units Per

Assembly

Description

1 21H7531* 1 Power Subframe Assembly

2 1621811 6 Screw, back mounting

3 0533783 4 Tie wrap

4 21H7259* 1 Back cover

5 90H6284 16 Shoulder screw

6 1621814 8 Screw, power distribution harness

7 23L3393 1 Power distribution harness (ac)

8 21H7468 2 Insulator

9 21H7467 2 Insulator

Chapter 10. Models S80 and S85 Parts

563
