Index Part Number Units Per
Assembly
Description
1 08L0411 1 Cover, top (covers blower housing)
2 97H9497 1 Top cover, back
3 93H8686 1 Fan monitor control (FMC) card
94H0800 4 Screw, FMC card
4 97H9483 1 Lower air baffle
5 97H9502 1 Cover plate (rear)
6 97H9485 1 I/O tray housing
00G1268 2 Screw, I/O tray housing
7 93H8185 1 Bulkhead card
93H8028 6 Standoff (black, SPCN connector)
1622344 6 Lockwasher, (SPCN connector)
93H6316 6 Standoff (Op, S1, S2 connectors)
1622344 6 Lockwasher (Op, S1, S2 connectors)
0438548 4 Screw (K, M, PCI connectors)
8 03N2655 1 Service processor card
9 See note. Adapters other than primary drawer Ultra SCSI.
10 See note. 2 Ultra SCSI adapters
11 46G3537 4 RIO standoff
12 08L1438 1 I/O planar
13 97H9465 1 Power distribution board
14 93H9156 1 Rail, left side
15 93H8819 1 Chassis
16 93H9159 1 Rail, right side
17 08L1336 2 Power supply
18 93H8868 1 DASD fan assembly
19 08L1468 1-2 SCSI backplane (35A)
20 93H8840* 1 DASD cage (included in chassis, 93H8819)
21 07L7747 1 DASD Banks Cover
22 See note. Up to 12 Disk drive, SCSI
23 See note. Up to 12 Disk drive carrier assembly
24 06H2792 1 Plate assembly
25 See note. 0-1 Tape drive
26 See note. 1 CD-ROM drive
07L7814 1 3.5 Inch diskette drive
27 93H8837* 1 Media cage (included in chassis, 93H8819)
28 97H9479 1 Media bank cover
29 06H7082 1 LCD indicator panel
93H1816 1 LCD indicator panel cable
30 07L9514 1 Drawer indicator panel card
31 41L6269 3 Blower
32 00G1268 4 Screw, bezel to center blower housing
33 08L0415 1 Bezel, center blower
34 08L0471 1 Housing, center blower
35 00G1268 3 Screw
36 08L0416 1 Blower power cable (center blower)
36 93H8564 1 Blower power cable (left blower)
Chapter 10. Models S80 and S85 Parts
565
